CUSTOMIZÁVEL

Servidor Supermicro AS-2024S-TR


AS-2024S-TR

Dual Socket SP3
AMD EPYC™ 7002/7003 Series Processors

icone
Quer saber mais sobre este produto?
Clique no ícone do Whats nesta página e fale com nossa equipe de vendas.
  • Processadores duplos AMD EPYC™ série 7003/7002
  • Suporta TDP de CPU de até 240 W
  • AMD®SP3
  • Até 4 TB 3DS ECC RDIMM, DDR4-3200 MHz; Até 4 TB 3DS ECC LRDIMM, DDR4-3200 MHz em 16 DIMMS
  • 3 PCIe 4.0 x16 de perfil baixo (LP)
  • 3 PCIe 4.0 x8 de perfil baixo (LP)
PART NUMBER AS-2024S-TR
Motherboard Super H12DSi-N6
Processor CPU
Dual Socket SP3
AMD EPYC™ 7002/7003 Series Processors
Core Count
Up to 64C/128T; Up to 256MB Cache per CPU
System Memory Memory
Memory Capacity: 16 DIMM slots
Up to 4TB: 16x 256 GB DRAM
Memory Type: 3200MHz ECC DDR4 RDIMM, LRDIMM
Memory Voltage
1.2 V
Error Detection
ECC
On-Board Devices Chipset
AMD SP3
Network Connectivity
2x 1GbE BaseT port(s)
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Input / Output LAN
1 RJ45 Dedicated IPMI LAN port
2 RJ45 1GbE LAN ports
USB
2 USB 2.0 port(s) (2 rear)
2 USB 3.0 port(s) (2 rear)
Video
1 VGA port(s)
Serial Port
1 COM Port(s) (1 COM)
DOM
2 SuperDOM (Disk on Module) port
Security Hardware
Trusted Platform Module (TPM) 2.0
Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features
Cryptographically Signed Firmware
Secure Boot
Secure Firmware Updates
Automatic Firmware Recovery
System Lockdown
PC Health Monitoring CPU
7 Phase-switching voltage regulator
Monitors for CPU Cores, Chipset Voltages, Memory.
FAN
Fans with tachometer monitoring
Pulse Width Modulated (PWM) fan connectors
Status monitor for speed control
Temperature
Monitoring for CPU and chassis environment
Thermal Control for fan connectors
Dimensions and Weight Height
3.5" (89mm)
Width
17.2" (437mm)
Depth
25.5" (648mm)
Package
11.4" (H) x 26.7" (W) x 34.5" (D)
Weight
Net Weight: 33.5 lbs (15.2 kg)
Gross Weight: 60 lbs (27.2 kg)
Available Color
Silver
Front Panel Buttons
Power On/Off button
Reset button
LEDs
HDD activity LED
Information LED
Network activity LEDs
Power Fail LED
Power status LED
Expansion Slots PCI-Express (PCIe)
3 PCIe 4.0 x8 LP slot(s)
3 PCIe 4.0 x16 LP slot(s)
Drive Bays / Storage Hot-swap
12x 3.5" hot-swap SATA/NVME drive bays (3.5" drive installation is tool-less, 2.5" drives will require screws. Default drive configuration is 8 SATA + 4 NVMe, other configurations require additional optional parts)
M.2
1 M.2 NVMe
M-key, 2280, 22110
Backplane HDD Backplane
Supports 12 SATA3 or 12 SAS3 or 4 NVMe
Note
Default drive configuration is 8 SATA + 4 NVMe, other configurations require additional optional parts
System Cooling Air Shroud
1 Clear Plastic Air Shroud(s)
Fans
3 Middle 80mm Fan(s)
Power Supply 920W Redundant Platinum Level power supplies
Dimension
(W x H x L)
76 x 40 x 336 mm
AC Input
920W: 100-127Vac / 50-60Hz
920W: 200-240Vdc / 50-60Hz
920W: 200-240Vac / 50-60Hz
+12V
Max: 75A / Min: 0A (100Vac-127Vac)
Max: 75A / Min: 0A (200Vac-240Vac)
5V SB
Max: 4A / Min: 0A
Output Type
Backplanes (gold finger)
Garantia Garantia de 3 anos on-site
